PA20° Module m4 Standard Involute Gear Hobber
2022-05-31 15:57:32
jiangxingTools
2575
PA20° Module m4 Standard Involute Gear Hobber
Tooth profile: DIN3972-2 standard, GB
Material：HSS M2, M35, ASP2030, ASP2052, S390
Accuracy：AA, A to DIN3968
Hob specification：OD 90 * Length 90 * Bore 32mm
Module: m4, with pressure angle: PA20°
相關文章
-
Shank-type gear shaper cutter with DIN 3972/II
